Author: mark_user

  • Ubuntu Desktop Setup

    Ubuntu Desktop Setup

    Turn of Multiple Workspaces

    Ubuntu by default has two or more workspaces activated by default. However, most people only ever use one workspace. When working, sometimes, the other workspace will pop out. This be behavior is obnoxious and unwanted by most end users.

    A quick solution is to just turn off all workspaces, except one.

    Firtst, find out how many workspces you have by checking the upper left corrner.

    Next, go to Setting, Multiptasking, Workspaces, set fixed number of workspaces to One.

    Move task bar to bottom and center

    Default ubuntu behavior is to place bar on left side of screen. I like to display my dock bar at the bottom and also show the trash can.

    You can extend the bar to the screen edges and this will push all icons to the left. But I persoanlly like to just center everything.

  • Customize App Icons in Ubuntu

    Customize App Icons in Ubuntu

    The question always arise is how can I change the icon images on my desktop in Ubuntu to ones I am familiar with. In this case, we are changing the blue Chromium to a Red Chromium icon.

    Download New Icon

    Download a png file of the new icon image and save to your Pictures folder. The file size shouldbe 32px x 32px.

    Find the App Launcher File

    Each installed app has a launcher file typically named appname_appname.desktop. It could be stored in a number of locations depending on how it was installed. Either manually or by RPM. The two main RPM for Ubuntu are Snap and Apt-Get. Snap is now the default Ubuntu RPM for applications.

    • /var/lib/snapd/desktop/applications/ (snap launcher files)
    • /usr/share/applications (apt installed packages launchers).
    • ~/.local/share/applications (user specific override system launchers).
    • /home/snap/chromium/current/ (User profile, cache, user level data).
    • /snap/chromium/current (the actual app itself).

    In our case the app was installed via snap so the original app launcher file is located in /var/lib/snapd/desktop/applications/.

    Edit Config File

    If we modify the original file locations, when an update occurs this file is overwritten with a new copy. So, any change will not survice a reboot or software updates. They are not persistant.

    Instead, we will create a file under the user’s folder and make any custom changes to that copy. The order of execution by default is any local fodler, then the original file location.

    First, make an applications directory under the local account. Next, make a copy of the appname_appname.desktop file in the original snap directory and place it in the new directory.

    mkdir -p ~/.local/share/applications
    cp /var/lib/snapd/desktop/applications/chromium_chromium.desktop ~/.local/share/applications/

    -p = create a directory and any necessary parent directories in the specified path, even if they don’t already exist.

    Next, open the new chromium_chromium.dekstop file.

    vim ~/.local/share/applications/chromium_chromium.desktop

    Find the line marked “Icon”, and make a copy of the line, then comment out the original. Next, modify the line to the path containing your new icon file.

    Make the file executable

    chmod +x ~/.local/share/applications/chromium_chromium.desktop

    Finally, update the desktop cache. The new icon should remain across reboots and software updates.

    update-desktop-database ~/.local/share/applications

  • Sizing Blog Images

    Sizing Blog Images

    Introduction

    You must consider both size and quality when creating a a blog image. Images have multiple conflicting interests. You must consider the specific blog post topic and the theme of the web site. Next you need to create an image that has a fast load time, often the image must be compressed, or a specific file format and finally it must be a quality image that makes the page appealing. We need to find the right balance and consider all these options.

    The most important image of any post is the main image displayed at the top of your blog post. This image is often called the “featured image”. I will explore some of observations that will give you some guidelines and suggestions to create these featured images.

    Make note that I will often reference exact image pixel dimentions. They will be displayed in the format of (680×382), meaning 680 pixels x 382 pixels. Generally speaking, you want the length of the featured image to be the wide of the main posting.

    General rules for any image

    Most often the best way to create a fast load time is to use compress images like jpeg and to use image ratio’s that produce a smaller image. But, smaller images tend to not look as sharp on high resolution monitors. Also, you can try using less colors when making an image.

    • Only crop from larger images images.
    • When making a custom images, use less colors.
    • Only resize larger image to smaller, not smaller to a larger.
    • Keep images < 200 kb for fast load time. Max can be 500 kb.

    Word Press size recommendations

    • Thumbnails 150 x 150
    • Medium 300 x 300
    • Large 1024 x 1024

    Image Resolution

    You may see references to this term. Although it is often discussed, I have not personally found it to be a very useful term and do not generally use it when creating iamges. I have included this concern as a reference only, in case you come across it.

    Image resolution is often described in dots-per-inch (dpi). Older displays are typically 72 dpi and modern displays are 200 – 400 dpi.

    Aspects ratios

    I feel that the best aspect ratio is 16×9 or 4×3. I choose based on the type or article I am writing. Ratio is based on wide x height of the image. So, for the fist example it is 16 wide x 9 high. the 800×450 is a good choice if most audiances will be accessiing by mobile devices.

    • 16×9: 1200×675 or 800×450 or 680×382
    • 4×3: 800×600
    • 2×1: 800×400, 600×300, 1170×585 (Slider)
    • 3×2: 800×600
    • 1×2: 1200×600
    • 4×1: 728×90 or 1900×250 (Header)

    File Formats

    I generally save my files in jpeg format, they have good compression and can saved in native format by most photo editors.

    • jpeg = General photos
    • gif = Animations and product photos.
    • png = Graphics requiring background transparency like icons and logos.
    • webP = Product banners, and featured images, good replacement for jpg.

    Guidelines

    • Background: 1920×1080, ratio 16:9, size < 20 MB
    • Header: 1280×720, ratio 16:9, size < 10 MB
    • Featured Image: 800×450, ratio 16:9, size <200 kb
    • Featured Image: 1200×900, ratio 4:3, size < 200kb
    • Banner: 600×160 (regular), ratio 15×4, size < 150 kb.
    • Logo: 100×100 (square), ratio 1:1 ratio, size < 100 kb
    • Site icon: 512×512, ratio 1:1

    References

    • https://blog.hubspot.com/website/image-size-for-website
    • https://wpjoli.com/blog/best-featured-image-size-wordpress/
    • https://calculateaspectratio.com/
  • Create & Deploy SSH Keys

    Create & Deploy SSH Keys

    Introduction

    Most folks are familiar with logging into a device or a a web page using a username and password. But a more secure method is to use a public private key exchange.

    Ubuntu comes preinstalled with all the tools necessary to create public private keys. The private key is kept hidden and secure. The public key will be give out freely. It is recommend that you rotate your key pair frequently as a safety precaution.

    In this article, we will look you how to generate a key pair, save your private key to a secure location, copy your public key to a remote host, troubleshoot, and introduce an auto login auto method.

    Create a key pair

    Login to the Linux computer that will be the device that you will connect from. This computer is the main control computer and where you will save your private key.

    Open a command line prompt and run …

    ssh-keygen -t rsa

    After the keys are generated, they will be stored under:

    Store the fingerprints of the remote PC

    To get started using the key exchange method for connecting via SSH, you must have an existing user account on the remote server that you want to connect too.

    But, before we can use the keys, we need to first store the remote server’s finger prints. We do this by sshing to the remote server three times.

    • Server’s host-name (i.e. server1).
    • Server’s FQDN (server1.mycomapny.com).
    • Server’s IP address (192.168.10.100).

    Each time you ssh, you will be cautioned that the server is unknown and do you want to store the fingerprint. Select yes.

    The remote server’s fingerprints will then be stored in a file under the specific user at /home/username/.ssh/known_hosts.

    Push the public key to the remote host

    Next, we need to push our public key to the remote server.

    This will create the ~/.ssh/authorized_keys directory on the remote server. If it does not exist, it will create it and place the public key inside it.

    Connect to remote device using key exchange

    Once you have created your keys, stored the remote server finger print, pushed your public key to it, you are now ready to login using the key exchange method instead of a username and password.

    Using putty, go to connection, auth, credentials and fill in the file path to your private key under “Public Key authentication”. Now when you connect, it will automatically do the key exchange and auto log you in.

    Add a passphrase to your private key

    For additional security, you can add a passphrase to your key. If the key gets compromised, bad actors will need to crack the passphrase first before they can use the key. It is essentially a password for your key.

    This may give you a little extra time, in the event of a compromise, for to generate new keys. It is best practice to add a passphrase when you create a key pair.

    To clear a passphrase, just hit enter, when it prompts you too add a phrase.

    Automatically present your private key

    If you add a passphrase to a key you will be prompted to enter it each time you logon to a remote server. If you have multiple servers to login to, it can become a burden.

    The solution is to temporary store your passphrase. It will only be kept as log as the current session is running. If you logout of you session the temp file is auto removed.

    It will be auto presented on login by running two small built in programs by using these commands.

    Use a key other than the default

    You can specify the file path to a specific key or if it is not stored in the default location by using the -i switch.

    -i = identity file (aka. private key)

    Troubleshoot File Permissions

    1. Verify .ssh and authorized keys belong to the correct user. chown -R user:user ~/.ssh
    2. Check permissions of files.
      • Authorized_keys = 644 = loaded on the remote servers you are connecting to
      • .ssh = 700
      • public key = 644
      • private key = 600
      • known_hosts = 644
      • home directory = /home/user = chmod go-w /home/user
    3. restart ssh after permissions update = $ service ssh restart

    Remove a host from authorized_host file

    If you replace a remote host that you connect to and reuse the IP address or the host name. they next time you connect you may get an error. This is because the remote host fingerprint has changed. The older fingerprint needs to be removed and and new fingerprint needs to be installed (see above).

    Reference

    https://www.digitalocean.com/community/tutorials/ssh-essentials-working-with-ssh-servers-clients-and-keys

  • Personality Matrix

    Personality Matrix

    Introduction

    Understanding personalities is key to a long work career. Here is a matrix I came across and found it to be accurate & true. You can use the chart to categorize work colleague and get a better understand their decision making. This can help you in avoiding pitfalls when communicating with them when conflict arises.

    Be aware that most people are a blend of two or more categories. However, one category is always dominate. So they may have some traits that combined but listed seperately in this article. Also, not all experts agree that the identified traits are exclusive to each category.

    THE PERSONALITY MATRIX

    4 square matrix

    Analytical

    Pro: Technical, task driven, avoids mistakes.

    Con: Not able to commit, slow, indecisive, needs to be right. not able to communicate well, avoids others, does not volunteer data or results.

    How to handle: Be clear and specific, don’t rush them, offer a solution they can evaluate step by step, & avoid yelling at them (emotional outbursts).

    Driver

    Pro: Results driven, prefers facts & data, likes to takes charge, appreciates quick decision-making.

    Con: Impulsive (Does not consider all the facts), likes control, get it done at any costs, not concerned if data is correct.

    How to handle: Be confident in your answers, get to the point, & present a clear and actionable plan.

    Amiable

    Pro: Gets along w everyone, wants to be liked, dislikes conflict, team player, supportive, prioritize relationships.

    Con: Will lie when necessary, less assertive, unable to make decisions, can not say no.

    How to handle: Reassure them that resolving the issue will not damage the relationship, encourage them to share their opinion, & emphasize the team and working together.

    Expressive

    Pro: Works quickly, persuasive, ambitious, social, high energy, likes new ideas.

    Con: Talkative, exaggerates, attacks others, poor at planning, likes to be recognized, somewhat disorganized, dominates conversations, can be superficial and place image over substance.

    How to handle: Actively listen to what they are saying, let them get a little emotional (helps prevent an increase in conflict), avoid being too blunt (they take criticism personally), & maintain a positive attitude (they like that).

  • Add a Personal Package Archive to Ubuntu

    Add a Personal Package Archive to Ubuntu

    Introduction

    PPA stands for Personal Package Archive. The primary purpose of a PPA is to provide a way for developers to distribute their own software. PPA are stored on Launchpad.net, which is the official website for PPA’s and is managed by Canonical. PPA’s can be created by anyone and you should only install a PPA from a trusted developer. Use at your own risk.

    A secondary purpose of PPA’s is for updating well known software. When Ubuntu reaches out to the official archive repository to get updates, these packages are often outdated and do not contain the latest available software. To get the most recent version, you can set up and install an appropriate PPA. Then, when you run the update command, your host will reach out to both the official archive and the PPA. Whom ever has the most recent software available, will get download and installed on your host.

    Typically, each PPA has a GPG key that needs to be installed. Each time an update is run, the keys are exchanged, to verify that you have connected to the correct repository, prior to any downloads. The key should be automatically installed with the initial PPA installation setup.

    After a PPA is initially setup. It should survive any system reboots. If you need to disable the PPA for any reason, you can open the PPA file under /etc/apt/sources.list.d/ and comment out the line calling the PPA. Then run an ‘apt update’ again, before running ‘apt upgrade’.

    Example PPA Install & Setup

    We will be using the popular PPA Apache2 for installation. This is a well known PPA and is maintained by ondrej, a Debian developer. So, it should be safe.

    1. apache2 -v (Note the current installed version).
    2. sudo apt -y install software-properties-common (to install a PPA, the add-apt-repository command is needed).
    3. sudo ls /etc/apt/trusted.gpg.d/ (Check the key was installed).
    4. sudo add-apt-repository ppa:ondrej/apache2 (The GPG keys are also installed w this command).
    5. sudo ls /etc/apt/sources.list.d/ (verify the package was installed).
    6. sudo apt update
    7. sudo apt install apache2
    8. apache2 -v (verify that the new version is installed).
    9. service apache2 restart (restart the service).

    References

    https://launchpad.net/~ondrej/+archive/ubuntu/apache2

    https://www.digitalocean.com/community/tutorials/how-to-handle-apt-key-and-add-apt-repository-deprecation-using-gpg-to-add-external-repositories-on-ubuntu-22-04
